Interrupts/diagnostic messages
6.3 Diagnostic messages
Analog input module F-AI 4xI 0(4)..20mA 2-/4-wire HF (6ES7136-6AA00-0CA1)
62 Manual, 08/2018, A5E41448857-AB
Supply voltage outside the nominal range
If the supply voltage L+ is outside the specified value range, the DIAG LED flashes and the
module is passivated.
When the voltage is then recovered (level must remain within the specified value for at least
1 minute (see Technical specifications (Page 64): Voltages, Currents, Potentials)), the DIAG
LED stops flashing. The module remains passivated.
Generally applicable information on diagnostics
Information on diagnostics that pertains to all fail-safe modules (for example, readout of
diagnostics functions or passivation of channels) is available in the SIMATIC Safety –
Configuring and Programming
(http://support.automation.siemens.com/WW/view/en/54110126) manual.

Siemens SIMATIC ET 200SP F-AI 4xI 0(4) 20mA 2-/4-wire HF Series Specifications

General

Input channels	4
Wiring type	2-/4-wire
Series	SIMATIC ET 200SP
Supply voltage	24 V DC
Rated value (DC)	24 V
Power loss, typ.	1.5 W
Interference voltage suppression for interference frequency f1 in Hz	50/60 Hz
Diagnostics function	Yes
Galvanic isolation	Yes
Potential separation channels	Yes
Potential separation between the channels and backplane bus	Yes
Module type	AI
Safety integrity level	SIL 3
Connection method	Push-in terminals
Operating voltage	24 V DC
Weight	200 g
Input current range	0(4)..20 mA
Product type designation	F-AI 4xI 0(4)..20mA 2-/4-wire HF
Analog value generation for the inputs	16 bits
Resolution	16 bit
Integration time/resolution per channel	Configurable
