Parameters/address space
4.1 Configuring the F-TM Count module
ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
Equipment Manual, V1.0, 01/2021, A5E47073911-AA
31
Assigning a PROFIsafe address
These are the three basic steps for assigning PROFIsafe addresses:
1. Configure the F-destination address and F-source address in the hardware configuration in
STEP 7 Safety and download the hardware configuration.
2. Identify the F-TM Count modules to which you want to assign the configured F-destination
and F-source addresses. F-destination addresses are generally assigned with lower numbers
(for example, less than 100) for GSDML configured devices, and should be within the range
of the F-CPU F-destination address range for PROFIsafe address type 1 devices.
3. Use "Assigning the F-source address and F-destination addresses to the F-I/Os" section in the
instructions for the S7-FCT V2.0 - Fail-safe Configuration Tool on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109763833) to assign the PROFIsafe
address (F-destination address together with F-source address) to the F-module before you
put it into operation.
SIMATIC Safety - Configuring and Programming manual
https://support.industry.siemens.com/cs/ww/en/view/54110126) for further information
about PROFIsafe address identification and assignment.
Configuring F-TM Count module parameters
You specify the properties of the F-TM Count module in STEP 7 using various parameters.
Depending on the settings, not all parameters are available.
You set the parameters of the module as follows:
1. Insert the IM 155-6 PN interface module from the hardware catalog under "Other field
devices->PROFINET I/O->I/O->SIEMENS AG->ET 200SP->Interface modules".
2. Insert the F-TM Count module from the hardware catalog under "Module->TM->Counting-
>F-TM Count". Select PROFIsafe V2.4 if you are using an S7-300 or S7-400 F-CPU. Select
PROFIsafe V2.6 version if you are using an S7-1200 or S7-1500 F-CPU.
3. Select the F-TM Count module (on the Device view or Device overview) and view the
module's "Properties" tab.
4. In the "Properties" view, on the "General" tab, select the drop-down arrows for "Module
parameters" and "TM-C parameters" to see a subset of the properties of the "F-parameters"
and "TM-C parameters".
5. Select "F-parameters" property or one of the "TM-C parameters" properties in the left-side
property tree and then set values in the right-side property fields.
6. Start the S7-FCT for the F-TM Count module and calculate the F_iParCRC.
7. Copy the F_iParCRC into the intended PROFIsafe parameter of the F-TM Count module.
8. A successful compile and download of your hardware configuration to an F-CPU
automatically configures your F-TM Count module.
