Parameters/address space
4.1 Configuring the F-TM Count module
ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
30 Equipment Manual, V1.0, 01/2021, A5E47073911-AA
Configuring F-TM Count module parameters
You specify the properties of the F-TM Count module in STEP 7 using various parameters.
Depending on the settings, not all parameters are available.
You set the parameters of the module as follows:
1. Insert an ET 200SP CPU or an ET 200SP PROFINET or PROFIBUS interface module from the
hardware catalog.
2. Insert the F-TM Count module from the hardware catalog under "Technology modules-
>Counting->F-TM Count".
3. Select the F-TM Count module (on the Device view or Device overview) and view the
module's "Properties" tab.
4. In the "Properties" view, on the "General" tab, select the drop-down arrows for "Module
parameters" and "TM-C parameters" to and see a subset of the properties of the
"F-parameters" and "TM-C parameters".
5. Select "F-parameters" property or one of the "TM-C parameters" properties in the left-side
property tree and then set values in the right-side property fields.
6. A successful compile and download of your hardware configuration to an F-CPU
automatically configures your F-TM Count module.
4.1.2 Using STEP 7 (TIA Portal) with GSDML (versions of TIA Portal prior to V17)
Configuring F-modules with a GSDML file
If you need to configure F-modules with a GSDML file, you need the S7-FCT in order to
calculate the F_iPar_CRC and assign the PROFIsafe addresses. Operating instructions and
additional information for the S7-FCT V2.0 - Fail-safe Configuration Tool can be found on the
Internet (https://support.industry.siemens.com/cs/ww/en/view/109763833).
You can find S7-FCT on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109762827).
