Siemens SIMATIC ET 200SP Equipment Manual

Interrupts/diagnostic messages
6.3 Interrupts
ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
74 Equipment Manual, V1.0, 01/2021, A5E47073911-AA
6.3 Interrupts
Diagnostic interrupts
The F-module generates a diagnostic interrupt for each diagnostics alarm described in
Diagnostic messages (Page 75).
The table below provides an overview of the diagnostic interrupts of the F-module. The
diagnostic interrupts are assigned either to one channel or the entire F-module:
Table 6- 6 Diagnostic interrupts of the F-TM Count module
Diagnostic interrupt Fault
code
Scope of
diagnostics
interrupt
Configurable
Overtemperature
16#0005
F-module
No
Parameter failure (invalid parameters)
16#0010
Supply voltage missing
16#0011
Mismatch of safety destination address (F_Dest_Add)
16#0040
Safety destination address not valid (F_Dest_Add)
16#0041
Safety source address not valid (F_Source_Add)
16#0042
CRC1 fault
16#0047
Inconsistent iParameters (iParCRC error)
16#004B
Transmission error: data inconsistent (CRC error)
16#004D
Transmission error: timeout (watchdog time 1 or 2 elapsed)
16#004E
Module is defective
16#0100
Watchdog tripped
16#0103
Invalid/inconsistent firmware present
16#011B
Diagnostic queue overflow
16#013E
F-address memory not accessible
16#030D
No valid F-address available
16#030E
Undertemperature
16#0312
Supply voltage too high
16#0321
Supply voltage too low
16#0322
Load voltage too low
16#0324
No pulses detected
16#030A
Channel
Yes
Failure in the input circuit
16#0313
No
Internal discrepancy failure
16#0315
Illegal A/B signal ratio
16#0500
Yes
Frequency outside specification
16#0501
No
