Siemens SIMATIC ET 200SP Equipment Manual

ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
Equipment Manual, V1.0, 01/2021, A5E47073911-AA
3
Preface
Preface
Purpose of the documentation
This device manual complements the system manual ET 200SP distributed I/O system.
General functions of the ET 200SP are described in the ET 200SP Distributed I/O System
system manual (http://support.automation.siemens.com/WW/view/en/58649293).
The information provided in this device manual and the system manual enables you to
commission the ET 200SP distributed I/O system.
The information in this manual and the system/function manuals provide support when you
commission the system.
A description of the F-system SIMATIC Safety can be found in the SIMATIC Safety –
Configuring and Programming programming and operating manual
(https://support.industry.siemens.com/cs/ww/en/view/54110126).
Conventions
CPU: When the term "CPU" is used hereafter, it refers to the fail-safe CPUs of the S7-
1200/1500 automation system, prior generation S7-300/S7-400 automation systems, and ET
200 CPUs.
STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the
configuration and programming software STEP 7 (TIA Portal).
Please observe notes marked as follows:
Note
A note includes important information on the product described in the documentation, on
handling the product, or on the part of the documentation to which you ought to pay special
attention.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
