Siemens SIMATIC ET 200SP Equipment Manual

ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
Equipment Manual, V1.0, 01/2021, A5E47073911-AA
81
Technical specifications
7
7.1 Specifications
6ES7136-6CB00-0CA0
General information
Product type designation
F-TM Count, 1x1Vpp sin/cos HF
Firmware version
V1.0
FW update possible
Yes
Product version
V1.0
usable BaseUnits
BU type A0
Color code for module-specific color identification
plate
CC01
Product function
I&M data
Yes; I&M0 to I&M3
Engineering with
STEP 7 TIA Portal configurable/integrated as of
version
Step 7 V17 or higher: use GSDML for prior ver-
sions
Supply voltage
Load voltage L+
Rated value (DC)
24 V
permissible range, lower limit (DC)
20,4 V
permissible range, upper limit (DC)
28,8 V
Reverse polarity protection
Yes
Input current
Current consumption, max.
50 mA; Without load, 150 mA with 300 mA En-
coder load
Encoder supply
5 V
Yes; 5.1 V ±3.5 %
Short-circuit protection
Yes; Electronic overload protection; no protection
on applying a normal or counter voltage.
Output current, max.
300 mA
Power loss
Power loss, typ.
1,25 W
Address area
Address space per module
Inputs
14 byte; S7-300/400F CPU, 13 byte
Outputs
5 byte; S7-300/400F CPU, 4 byte
Digital inputs
Number of digital inputs
1; (Counter Input)
Digital inputs, parameterizable
Yes

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
