Siemens SIMATIC ET 200SP Equipment Manual

ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
Equipment Manual, V1.0, 01/2021, A5E47073911-AA
87
Parameter data record
B
B.1 Parameter defaults and dependencies when configuring with
GSD file
When configuring the module with a GSD file, remember that the setting of some parameters
are dependent on each other.
F-TM Count module and encoder
The following are F-TM Count module default parameters:
Channel activation
Count/Pos input
Measuring
Signal monitoring
Enabled
Enabled
Enabled
Enabled
The following are encoder default parameters:
Signal type Invert direction Pulses per revolu-
tion
Signal evaluation Reaction to
N signal
Sin/Cos
Disabled
1024
Quadruple
No reaction
The following are F-TM Count default parameters using STEP 7 or GSD:
High limit Start
value
Low limit Counting
violation
Reset
upon
violation
Reaction
to Gate
start
STEP 7
2147483647
0
-2147483648
Continue
Start value
Set to start
GSD
2147483647
1
0
1
0
1
,
2
Continue
Start value
Set to start
1
Parameter errors result whenever "Low Limit" >= "High Limit", "High Limit" < "Start Value", or "Start
Value" < "Low Limit".
2
Signed values are not supported using FCT V2.0. Negative values must be entered as their equiva-
lent two's compliment values (for example, 2147483648 = - 2147483648 and 4294967295 = -1).
Measured value
The following are measured value default parameters:
Measured value
Update time
Time base (velocity)
Counts/Unit (velocity)
Frequency
100
0
1
Period
100
0
1
Velocity
100
0
1
