Siemens SIMATIC ET 200SP Equipment Manual

Parameters/address space
4.5 Parameters of the F-TM Count
ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
34 Equipment Manual, V1.0, 01/2021, A5E47073911-AA
4.5 Parameters of the F-TM Count
The following parameter settings are possible:
Table 4- 3 Settable parameters and their default setting
Parameter Value range Default setting Parameter
reassign-
ment in
RUN
Scope
STEP 7 (TIA Portal);
STEP 7; GSD file
F-parameters
Manual assignment of
F-monitoring time
Check box:
• Enable
•
Disable
Disable
No
Module
F-monitoring time
1
14 to 65535 ms in 1 ms steps
150 ms
No
Module
F-destination address
1 to 65534
Address supplied by
F-CPU (Always ena-
bled)
No
Module
TM-C parameters
Signal Monitoring
• Disable
•
Enable
Enable
No
Channel
Encoder related parameters
Signal type
2
• Sin/Cos encoder (A, B, N)
•
Sin/Cos encoder (A, B)
Sin/Cos encoder (A,
B, N)
No
Channel
Invert direction
• Disable
• Enable
Disable
No
Channel
Pulses per revolution
0 to 32767
1024
No
Channel
Reaction to signal N
• No reaction to signal N
• Synchronization at signal N
No reaction to sig-
nal N
No
Channel
Counter parameters
High counting limit
-2147483647 to 2147483647
2147483647
No
Channel
Start value
-2147483648 to 2147483647
0
No
Channel
Low counting limit
-2147483648 to 2147483646
-2147483648
No
Channel
Reaction to violation of
a counting limit
• Continue counting
•
Stop counting
Continue counting
No
Channel
Reset when counting
limit is violated
• Start value
• Opposite counting limit
Start value
No
Channel
Reaction to gate start
• Set to start value
•
Continue with current value
Set to start value
No
Channel
