Interrupts/diagnostic messages
6.4 Diagnostic messages
ET 200SP F-TM Count 1x1Vpp sin/cos HF (6ES7136-6CB00-0CA0)
76 Equipment Manual, V1.0, 01/2021, A5E47073911-AA
The following diagnostics can be signaled:
Table 6- 7 Diagnostics alarms, their meaning and possible remedies
Diagnostics alarm Fault
Meaning Solution
An excessively high temperature was
measured in the F-module.
• Operate the F-module within the
specified temperature range (see
Technical specifications).
• Once the temperature has been
reduced and returns to the speci-
fied range, the F-module must be
removed and reinserted or the
power switched OFF and ON.
Parameter failure (invalid
parameters)
On detection of invalid parameters, the
module remains present in the system but
goes to an unparameterized state and the
module LEDs give an immediate indica-
tion of the fault.
The module is included in STEP 7 (TIA
Portal V17 or later), which includes de-
tailed dependency checks. However,
configuration may also be accomplished
using the GSDML, which contains limited
dependency checking. This error is seen
when using the GSDML to configure the
module since there is limited dependency
checking performed by the GSDML.
Possible causes:
• i-Parameter CRC error
• Invalid i-parameters (for example,
invalid selection, parameter out-of-
range, unsupported feature selected,
and wrong value of reserved field)
• Any PROFIsafe parameterization prob-
lem detected by the PROFIsafe driver
Check the i-Parameter CRC, i-
parameter, and PROFIsafe parameter
assigned to the F-module in the GSDML
configuration.
Missing or insufficient supply voltage L+
Possible causes:
• Operating the F-module outside the
specified supply voltage range
• Critical overvoltage range exceeded
• Operate the F-module within the
specified supply voltage range.
• After a critical over-voltage event,
once the voltage returns to the
specified range, the F-module must
be removed and reinserted or the
power switched OFF and ON.
