Installing the Configuration Package
5-2
FM 351 Positioning Module
C79000-G7076-C351-02
Installation
The entire configuration package is located on the CD supplied. You install the
configuration package as follows:
1. If you already have a configuration package on your system, uninstall it.
2. Insert the CD in the CD drive of your PC/programming device.
3. Start the software installation dialog in Windows 95/Windows NT/Windows 98
by clicking the “Add/Remove Programs” icon in the “Control Panel”.
4. In this dialog, select the CD drive and the folder FMx51\Disk1, then select the
file Setup.exe and start the installation.
5. Follow the instructions displayed by the installation program step by step.
Result: The components of the configuration package are installed in the
following folders:
– SIEMENS\STEP7\S7LIBS\FMx51LIB: FCs, UDTs
– SIEMENS\STEP7\S7FABS: Configuration software, readme, online help
– SIEMENS\STEP7\EXAMPLES: Examples
– SIEMENS\STEP7\S7MANUAL\S7FABS: Getting Started, manuals
Note
If you installed STEP 7 in a folder other than SIEMENS\STEP7, this folder is
entered.
