Modes and Jobs
9-9
FM 351 Positioning Module
C79000-G7076-C351-02
Data Used in the Channel DB
Address Name Type Initial Value Comment
15.2 DIR_M BOOL FALSE 1 = direction minus
15.3 DIR_P BOOL FALSE 1 = direction plus
15.7 DRV_EN BOOL FALSE 1 = activate drive enable
16.0 MODE_IN BYTE B#16#0 1 = jogging
17.0 MODE_TYPE BYTE B#16#0 1 = rapid speed
0 = creep speed
23.0 ST_ENBLD BOOL FALSE 1 = start enabled
23.1 WORKING BOOL FALSE 1 = positioning active
23.2 WAIT_EI BOOL FALSE 1 = axis waiting for ext. enable
34.2 EI_OFF BOOL FALSE 1 = do not evaluate enable input
Terminating Jogging
The “jogging” mode is terminated in the following situations:
• When you release the “jogging” button (DIR_M or DIR_P=0)
• When the FM 351 receives a STOP signal (STOP=1)
• When the actual value of a synchronized linear axis reaches the limit of the
working range. Travel is then only possible in the opposite direction.
After terminating the positioning operation, travel can be continued in either
direction.
Aborting Jogging
The “jogging” mode is aborted in the following situations:
• The drive enable signal is cleared (DRV_EN=0)
• A travel range limit is passed on a linear axis.
