Siemens SIMATIC Ident Function Manual

Setting parameters for blocks
3.4 Programming Ident blocks
Ident profile and Ident blocks, standard function for Ident systems
44 Function Manual, 10/2018, C79000-G8976-C387-04
Table 3- 21 Explanation of the "Set_Ant_RF300" block
Parameter
Data type
Description
ANTENNA Bool 0 = turn antenna off
1 = turn antenna on
Set_Ant_RF600
Figure 3-18 "Set_Ant_RF600" block
Table 3- 22 Explanation of the "Set_Ant_RF600" block (RF620R/RF630R)
Parameter
Data type
Description
ANTENNA_1 Bool 0 = turn antenna 1 off
1 = turn antenna 1 on
ANTENNA_2 Bool 0 = turn antenna 2 off
1 = turn antenna 2 on
TAGLIST_INIT Bool 0 = TagList is reset
1 = the existing TagList continues to be used
