Setting parameters for blocks
3.4 Programming Ident blocks
Ident profile and Ident blocks, standard function for Ident systems
Function Manual, 10/2018, C79000-G8976-C387-04
43
The "Read_UID" block reads the UID of an HF transponder. The UID always has a fixed
length of 8 bytes.
Figure 3-16 "Read_UID" block
Table 3- 20 Explanation of the "Read_UID" block
IDENT_DATA Any / Variant UID
Note:
For Variant, currently only an "Array_of_Byte"
with a variable length can be created. For Any,
other data types/UDTs can also be created.
With the aid of the "Set_Ant" block, you can turn antennas on or off. There are different
blocks for RF300 and RF600. The "Set_Ant_RF300" block can also be used for RF200,
MOBY D and MOBY U. The "Set_Ant_RF600" block relates only to the RF620R and
RF630R readers.
Figure 3-17 "Set_Ant_RF300" block
