Configuring firmware
3.6 "Power" tab
Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX-59A)
26 Operating Instructions, 10/2023, A5E52427534-AA
Firmware
setting
Value Setting in
delivery state
Meaning
USB Port X64
Wake Capability
Enabled
The USB port X64 is allowed to wake up the system from the
S4/S5.
Disabled
x
x
The USB port X64 is not allowed to wake up the system from the
S4/S5.
USB Port X65
Wake Capability
Enabled
The USB port X65 is allowed to wake up the system from the
S4/S5.
Disabled
x
x
The USB port X65 is not allowed to wake up the system from the
S4/S5.
USB Port X66
Wake Capability
Enabled
The USB port X66 is allowed to wake up the system from the
S4/S5.
Disabled
x
x
The USB port X66 is not allowed to wake up the system from the
S4/S5.
Internal USB
Port X9300
Wake Capability
Enabled
The internal USB port X9300 is allowed to wake up the system
from the S4/S5.
Disabled
x
x
The internal USB port X9300 is not allowed to wake up the
system from the S4/S5.
Wake on LAN 1
(X1 P1)
Enabled The LAN controller of the onboard Ethernet interface "X1 P1" can
wake from S4/S5.
Disabled
x
x
The LAN controller of the onboard Ethernet interface "X1 P1"
cannot wake from S4/S5.
Wake on LAN 2
(X2 P1)
Enabled
The LAN controller of the onboard Ethernet interface "X2 P1" can
wake from S4/S5.
Disabled
x
x
The LAN controller of the onboard Ethernet interface "X2 P1"
cannot wake from S4/S5.
3.6.1 Advanced CPU Control
Calling "Advanced CPU Control" tab
Select: "Setup Utility (Page 10)" > "Power" > "Advanced CPU Control".
Firmware
setting
Value Setting in
delivery state
Meaning
BX-56A
BX-59A
Intel (VMX)
Virtualization
Technology
Enabled
x
x
Enable or disabled Support of Intel Virtualization Technology.
Disabled
VT-d
Enabled
x
x
Enable or disable the Intel Virtualization Technology for Direct
I/O.
Disabled
AES
Enabled
x
x
The secure encryption method AES (Advanced Encryption
Standard) is supported by hardware, which speeds up encryption
and decryption.
Disabled
The AES function is disabled.
