Page #29 background imageLoading...
Page #29 background image
Configuring firmware
3.7 "Boot" tab
Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX-59A)
Operating Instructions, 10/2023, A5E52427534-AA
29
Firmware setting Value Setting in delivery
state
Meaning
NVME Boot
Enabled
x
x
Booting from NVME devices is permitted.
Disabled
Booting from NVME devices is not permitted.
SATA Boot
Enabled
x
x
Booting from SATA devices is permitted.
Disabled
Booting from SATA devices is not permitted.
Timeout
[Number]
0
0
Delay time in seconds during booting so that the user has
time to press the hotkey to open the firmware selection
menu.
The input range is from 0 to 1800.
EFI (Page 29)
EFI Boot Order Settings.
3.7.1 "EFI"
List of boot media.
Calling "EFI"
Select: "Setup Utility (Page 10)" > "Boot" > "EFI".
If "Add Boot Options" = "Auto", the boot media is grayed out and cannot be changed.
If "Add Boot Options" = "First" or "Last", the following can be changed:
Sequence of the boot media: <F6>, <F5> or <+>, <-> keys
List of valid boot media: <Enter> key
Firmware setting
Meaning
EFI USB Device
EFI boot order settings.
EFI Network x for IPv4
Windows Boot Manager (M.2)
