Siemens SIMATIC IPC BX-56A User Manual

Configuring firmware
3.4 "Advanced" tab
Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX-59A)
Operating Instructions, 10/2023, A5E52427534-AA
21
3.4.13 "SATA Configuration"
Calling "SATA Configuration"
Select: "Setup Utility (Page 10)" > "Advanced" > "SATA Configuration".
Firmware
Setting
Value Setting in
delivery state
Meaning
BX-56A
BX-59A
Serial ATA Port
(X9001)
[Empty]/[Drive
name]
Software
Preserve
SUPPORTED/Unk
nown
Port
Enabled
x
x
Enable or disable SATA Port.
Enabled
Hot Plug
Enabled
x
x
Designate this Port as Hot Pluggable or not.
Disabled
3.4.14 "Extension module Configuration"
Calling "Extension module Configuration"
Select: "Setup Utility (Page 10)" > "Advanced" > "Extension module Configuration".
Firmware
setting
Value Setting in
delivery state
Meaning
BX-56A
BX-59A
PCI Express Slot (X301)
PCIE (BUS:xx
Device:xx
Function:xx)
Present/Not
Presented
The PCIE bus device function is present or not.
PCIe Express
Port Enable
Enabled
x
x
Control the PCI Express Root Port.
Disabled
PCIe Max Link
Speed
Auto
x
x
Configure PCIe Speed.
Gen1
Gen2
Gen3
Gen4
Detect Timeout
[Number]
0
0
The number of milliseconds reference code will wait for link to
exit. Detect state for enabled ports before assuming there is no
device and potentially disabling the port.
The input range is from 0 to 65535.
PCI Express Slot (X302)
PCIE (BUS:xx
Device:xx
Function:xx)
Present/Not
Presented
The PCIE bus device function is present or not.
