Siemens SIMATIC IPC327G

Technical specifications
7.5 Hardware descriptions
SIMATIC IPC327G
Operating Instructions, 09/2021, A5E51366275-AA
65
7.5.2 External interfaces
7.5.2.1 Overview of external interfaces
Interface
Position
Description
USB
External
• 4 × USB 3.1 Gen2 (up to 10Gb/s)
Ethernet port
External
• 2 × RJ45 Ethernet 10/100/1000 Mbps
DisplayPort
External
• 2 × DP++
COM
External
9-pin D-sub, either:
• 2 × RS232/RS485/RS422
• 2 × RS232
Audio (optional)
External
Connection for analog audio source and speaker
7.5.2.2 USB 3.1 port
Pin
Short name
Meaning
Input / output
1
VBUS
+ 5 V (Power switch)
Power out
2
D-
Data channel USB2
Input / output
3
D+
Data channel USB2
Input / output
4
GND
Ground
–
5
RX-
Data channel USB3
Input
6
RX+
Data channel USB3
Input
7
GND
Ground
–
8
TX-
Data channel USB3
Output
9
TX+
Data channel USB3
Output
7.5.2.3 DC in connector
Pin
Short description
1
+24V
2
GND
