Siemens SIMATIC IPC327G

Technical specifications
7.5 Hardware descriptions
SIMATIC IPC327G
Operating Instructions, 09/2021, A5E51366275-AA
71
7.5.3.3 USB 2.0 pin header
Pin
Signal
1
VBUS_USB1
2
VBUS_USB2
3
USB1_D-
4
USB2_D-
5
USB1_D+
6
USB2_D+
7
GND
8
GND
9
GND
10
GND
7.5.3.4 USB 2.0 port
Pin
Short description
Meaning
1
USB_P5V_fused (O)
+5 V, fused
2
USB_D0M (I/O)
Data–
3
USB_D0P (I/O)
Data+
4
USB_GND
GND
7.5.4 System resources
7.5.4.1 Currently allocated system resources
Currently allocated system resources
All system resources (hardware addresses, memory utilization, interrupt assignment, DMA
channels) are assigned dynamically by the Windows operating system, depending on the
hardware equipment, drivers and connected external devices. You can view the current
allocation of system resources or possible conflicts in the Control Panel.
