Detailed descriptions
16.2 BIOS Setup
SIMATIC IPC427C
Operating Instructions, 04/2009, A5E02414743-01
117
16.2.4 Main menu
Figure 16-3 Main menu
Settings in the main menu
In the main menu, you can move up and down to select the following system configuration
boxes by means of the [↑] up and [↓] down cursor keys:
Field Meaning
System Time For viewing and setting the current time
System Date For viewing and setting the current date
by submenus
Serial ATA Port 0 Type of installed drives
Serial ATA Port 1 Type of installed drives
Boot options Used for setting the boot options
Keyboard Features Used for setting the keyboard interface (Numlock)
Hardware Options Used for setting the hardware options
