Expansions and Configurations
10.4 Installing/Removing Compact Flash Cards
SIMATIC IPC427C
66 Operating Instructions, 04/2009, A5E02414743-01
10.4.3 Installing/removing a built-in Compact Flash card
Steps for removing a built-in Compact Flash card
1 Remove the four screws of the
cover plate and remove it
2 Press the eject button ① and
carefully remove the
CompactFlash card from the
holder.

3 Fasten the cover plate again.
To install, carry out the above steps in reverse order.
