Siemens SIMATIC IPC427C - 15 Dimension Drawings; Overview of the Dimensional Drawings

SIMATIC IPC427C
Operating Instructions, 04/2009, A5E02414743-01
97
Dimension drawings
15
15.1 Overview of the dimensional drawings
This section contains the following dimension drawings:
●
Dimension drawings of the device (Page 98)
●
Dimension drawings of the device with mounting brackets (Page 99)
●
Dimensional drawings of the device with vertical mounting angles (Page 101)
●
Dimensional drawings of the device with expansion frames (Page 102)
●
Dimension drawing of the blanking plate (Page 103)
Note
The dimensions are always given in in mm and inch (above: Millimeter, below: Inch
