Expansions and Configurations
10.2 Memory expansion
SIMATIC IPC427C
58 Operating Instructions, 04/2009, A5E02414743-01
Installing a memory module
How to install a memory module
1 Set the memory module in the mount
tilting forward.
2 Carefully push the memory module back into the heat sink until it fully engages.
3 Close the device.
Display of the current memory configuration
The new memory configuration is detected automatically. System RAM, Extended RAM and
Cache SRAM are displayed during device startup.
