Maintaining and servicing your device
7.4 Installing and removing hardware
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
157
Flip the hard disk holder and remove the
marked screws.
ors from the SSD
For installation, follow the steps for removal in reverse order. Insert the backup battery back
into the holder and close the device.
Repair information (Page 150)
Replacing back-up battery (device with 12" display) (Page 154)
