Siemens SIMATIC IPC477D User Manual

Overview
1.2 Design of the built-in units
SIMATIC IPC477D, IPC477D PRO
18 Operating Instructions, 11/2016, A5E31347228-AF
1.2.3
Touch/Key devices with resistive single touch screen
The following figures show the Touch/Key device (15" only) without DVD drive and without
PCIe card as an example.
Front and side views
①
Recesses, each of which for a mounting clip
②
Display with touch screen
③
USB port
Bottom view
The bottom view shows a device with 24 V DC power supply and PROFIBUS interface.
①
Recesses, each of which for a mounting clip

Siemens SIMATIC IPC477D Specifications

General

Brand	Siemens
Model	SIMATIC IPC477D
Category	Industrial PC
Language	English
