Siemens SIMATIC IPC477D - Operator Controls or Touch;Key Devices with Resistive Single-Touch Screen

Overview
1.2 Design of the built-in units
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
23
1.2.5
Operator controls or touch/key devices with resistive single-touch screen
Note
If you open the sealed cover for the front USB port, the degree of protection
IP65 for the
front of the device is no longer guaranteed.
①
Function keys
②
Keypad with alphanumeric and numeric keys
③
Sealed cover for the USB port
④
Control keys, cursor keys, On/Off switch
