Mounting and connecting the device
3.1 Preparing for mounting
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
55
Labeling the function keys
Use labeling strips for project-related labeling of the function keys of your device.
You will find labeling strip templates with a scale of 1:1 as a Word file:
● On the Internet at:
Labeling strips for 15" widescreen
(http://support.automation.siemens.com/DE/view/en/59000814)
If you would like to make your own labeling strips, you can find the dimensions under
"Dimension drawing of labeling strips (Page 207)".
Note
Do not write on the keyboard to label the function keys.
Any printable and writable film can be used as l
abeling strip. The permitted thickness of the
mm. Do not use paper labeling strips.
● The device is installed
● Template for labeling strips is available
1. Edit the template on a PC and then print it.
2. Apply a fixation spray film to the labeling strips.
The printout can be made water and smudge-proof with a fixation spray. The color printer
ink will not bleed onto the keyboard film as well.
3. Cut out the labeling strip.
4. Cut the corners at a 45° angle so that it is easier to slide the strip into the slot.
5. When the ink has dried, slide all but the last 3 cm of the labeling strip into the guide.
