Technical information
8.4 Technical specifications
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
209
Power consumption (DC)
The table below shows the maximum power consumption of the devices with and without
expansions, depending on the processor.
Device
type
Intel Celeron processor
Intel Core i3 processor
Intel Core i7 processor
Without ex-
pansion
With PCIe
and DVD
Without ex-
pansion
With PCIe
and DVD
Without
expansion
With PCIe
and DVD
12" Touch
53 W
67 W
58 W
72 W
59 W
73 W
15" Touch
61 W
75 W
67 W
80 W
68 W
82 W
15"
Touch/Key
61 W 75 W 67 W 80 W 68 W 83 W
19" Touch
59 W
73 W
64 W
78 W
66 W
80 W
22" Touch
67 W
80 W
72 W
86 W
74 W
88 W
The values are determined under the following test conditions:
● 24 V DC supply voltage
● Internal storage media:
– One SSD
– Two CFast cards
● External storage media: 4 x USB 3.0, maximum 2 high-current
● 2 active LAN interfaces
● Simulated loads for devices with expansions:
– 5 W PCIe
– 7.5 W DVD
● BIOS setting: High Performance
● "Dim" setting with SetBrightness: 100 %
