8.4 Technical specifications
SIMATIC IPC477D, IPC477D PRO
218 Operating Instructions, 11/2016, A5E31347228-AF
Power consumption (DC)
The table below shows the maximum power consumption of PRO devices depending on the
processor.
Device type
Intel Celeron processor
Intel Core i3 processor
Intel Core i7 processor
15" Touch
61 W
67 W
68 W
19" Touch 59 W 64 W 66 W
21" Touch
67 W
72 W
74 W
The values are determined under the following test conditions:
● 24 V DC supply voltage
● Internal storage media:
– One SSD
– Two CFast cards
● External storage media: 4 x USB 3.0, maximum 1 high-current
● 2 active LAN interfaces
● BIOS setting: High Performance
● "Dim" setting with SetBrightness: 100 %
Electromagnetic compatibility
Interference emission EN 61000-6-4; CISPR 22 Class A;
FCC Class A
Immunity with regard to conduct-
ed interference on the supply lines
± 2 kV according to IEC 61000-4-4; burst
± 1 kV according to IEC 61000-4-5; symmetrical surge
± 2 kV according to IEC 61000-4-5; asymmetrical surge
Noise immunity on signal lines ± 2 kV according to IEC 61000-4-4; Burst; Length > 3 m
± 1 kV according to IEC 61000-4-4; Burst; length < 3 m
± 2 kV according to IEC 61000-4-5; Surge, symmetric,
length > 30 m
Immunity to electrostatic dis-
charge
± 6 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference 10 V/m, 80 to 2000 MHz
80% AM according to IEC 61000-4-3
3 V/m, 2 to 2.7 GHz
10 V, 10 kHz to 80 MHz according to IEC 61000-4-6
Immunity to magnetic fields
100 A/m, 50/60 Hz according to IEC 61000-4-8
