Technical information
8.4 Technical specifications
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
221
Interfaces
COM 1 RS 232, max. 115 kbps, 9-pin, D-sub connector
DVI
Connection of display devices with DVI connection
Display port (DPP) Connection of display devices with DPP connection
Keyboard
Connection via USB port
Mouse
Connection via USB port
USB Back of device:
• 4 × USB 3.0
• Max. 1 high-current can be operated at the same time
• Max. 5 W for all USB devices
PROFIBUS/MPI
• Transmission rate
• Operating modes
9-pin, 2-row, electrically isolated, D-sub socket, CP 5622 com-
patible
• 9.6 kbps to 12 Mbps
• DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
PROFINET 3 x RJ45 connection, CP 1616 compatible onboard interface
based on ERTEC 400
10/100 Mbps, isolated
Ethernet
1
2 x RJ45 connection, Intel 82579LM and Intel 82574L
10/100/1000 Mbps, electrically isolated, teaming-capable
2
Or
For PROFINET variants:
1 x Ethernet RJ45, Intel 82579LM
1
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
2
Teaming can be set and initiated in the configuration interface. In teaming operation, jumbo
frames, e.g. for the camera application, are not supported.
