Mounting and connecting the device
3.3 Mounting the PRO device
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
69
Note
Liability disclaimer
The device is mounted to a pedestal or a support arm via the mechanical interface with
screws. Siemens AG assumes no liability for the consequences of incorrect installation.
Warranty at risk
If you do not install the HMI device in accordance with the specifications in these operating
instructions, the warranty for the device is voided.
Always install the device according to these operating instructions.
If the seal on the backplane cover is damaged, it can be repaired. For a repair scenario,
following the instructions in the section "Repair information (Page 150)".
IP65 degree of protection and Enclosure Type 4X / 12 (indoor use only) at risk
If there are no seals on the mechanical interfaces or if they are damaged, IP65 degree of
protection and Enclosure Type 4X
/ 12 (indoor use only) is at risk. Check the condition and
ing of the seals.
Damaging the seal when opening
If the device has not been opened for a long time, the backplane cover or terminal
compartment cover may stick to the seal of the enclosure. Opening the device with
excessive force or with tools will destroy the seal. Spray and water jets as well as
penetrating substances can then damage the device.
Open the terminal compartment cover gently, without too much pressure.
