Siemens SIMATIC PCS 7 - Redundancy Status on the os Server

Installing updates and service packs
3.3 Checking plant status
Compendium Part D - Operation and Maintenance (V9.0)
22 Operating Manual, 02/2018, A5E43228948-AA
3.3.7
Redundancy status on the OS server
The following internal variables of the "Redundancy" group can be checked in the variable
management area on the OS server to determine the redundancy status of the OS server.
The values of the internal variables can be determined in the OS server's WinCC Explorer at
runtime. These are displayed in the "Value" column.
When attempting to deactivate runtime on one of the two redundant servers, a check is
made in the system to see whether there is a redundancy problem and this will be indicated
in the event of an error.
Meaning of the variables
Variable name
Meaning
@RM_MASTER The @RM_MASTER variable is set to identify the server com-
puter as the master. The @RM_MASTER variable will be reset if
the server computer is in "standby".
@RM_MASTER_NAME The computer name of the master server is specified in the
@RM_MASTER_NAME variable.
@RM_SERVER_NAME
This variable contains the computer name of the OS server.
@RM_OFFLINE_UA_NAME Used for diagnostic purposes, a separate variable is created
with a corresponding archive name for each user archive.
