Replacing hardware
4.1 Use of new hardware
Compendium Part D - Operation and Maintenance (V9.0)
Operating Manual, 02/2018, A5E43228948-AA
39
Example: Using H-CPU V4.5 in PCS 7 V6.1 SPx
The following updated AS hardware components can be used with PCS 7 V6.1 SP2 in
addition to the AS hardware components listed in the document titled "PCS 7 - Released
Modules" (extract from the PCS 7 V6.1 SP2 "Readme.txt" file):
CPU 41X-? H V4.5 6ES7 412-3HJ14-0AB0, 6ES7 414-4HJ14-0AB0,
CPU 41X-???04 V4.0 / V4.1 6ES7 414-3XJ04-0AB0, 6ES7 416-2XK04-0AB0,
6ES7 416-3XL04-0AB0, 6ES7 417-4XL04-0AB0,
6ES7 414-4HJ04-0AB0, 6ES7 417-4HL04-0AB0,
The "Readme.txt" file contains concrete information about the additional release of H-CPU
V4.5. The HSP and the required meta information will be supplied as software as of PCS 7
V6.1 SP2.
The following overview of the release schedule should clarify this point:
Replacement-compatible operation
Replacement-compatible operation
10/2/2007 HSP of H-CPU V4.5 for
Download using Entry ID 26609816 in the
The order of the delivery releases shows that H-CPU V4.5 can only be used with its full
range of functions starting with PCS 7 V6.1 SP2 or V7.0 SP1. The HSP of H-CPU V4.5 was
officially released only for PCS 7 V7.0 SP1. The H-CPU must be operated as a replacement
for PCS 7 V6.1 SP1. We recommend an upgrade to PCS 7 V6.1 SP2.
New functions such as "firmware update in RUN" can only be used because you can now
configure the H-CPU V4.5 in PCS 7.
None of this is possible in PCS 7 V6.1 SP1 or V7.0. The H-CPU V4.5 is used as a
replacement component here (see section (Page 40)).
If an HUP/HSP is used in a PCS 7 project for redundant components, such as H-CPU or IM
153-2, you will have to replace both redundant components during a maintenance interval.
