Siemens SIMATIC PCS 7 Operation And Maintenance

Replacing hardware
4.3 Procedure for replacing hardware
Compendium Part D - Operation and Maintenance (V9.0)
Operating Manual, 02/2018, A5E43228948-AA
43
Component
Manual/section
Note
ET 200iSP module Manual "SIMATIC Distributed I/O ET
200iSP"
7)
, section "Removing and in-
serting electronics modules during
operation"
ET 200iSP tolerates a single module gap during
ongoing operation (RUN). Never remove more
than one electronic module during operation.
PS and CPU of a standard AS Manual "S7-400 Programmable Con-
trollers Hardware and Installation"
8)
,
section "Maintenance"
H-CPU of an H system Manual "SIMATIC Fault-tolerant Sys-
tems S7-400H"
5)
, section "Failure and
replacement of components during
operation"
To swap a CPU, the corresponding power sup-
ply must be switched off.
CP 443-1 in H system Swapping can be performed with the power
supply switched on.
CP 443-5 in H system To swap an active DP master, the correspond-
ing power supply must be switched off.
1)
Manual "SIMATIC ET 200SP ET 200SP HA Distributed I/O System"
(https://support.industry.siemens.com/cs/ww/en/view/109747237)
2)
Manual "SIMATIC ET 200SP HA Interface Module IM 155-6 PN HA (6DL1155-6AU00-
0PM0)" (https://support.industry.siemens.com/cs/ww/en/view/109747239)
3)
Manual "SIMATIC Distributed I/O Device ET 200M"
(https://support.industry.siemens.com/cs/ww/en/view/1142798)
4)
Document "New PROFIBUS Interface Modules for ET 200M, DP/PA Link and Y Link"
(https://support.industry.siemens.com/cs/ww/en/view/23372259)
5)
Manual "SIMATIC Fault-tolerant Systems S7-400H"
(https://support.industry.siemens.com/cs/ww/en/view/82478488)
6)
Manual "SIMATIC Bus Links DP/PA Coupler, Active Field Distributors, DP/PA Link and Y
Link" (https://support.industry.siemens.com/cs/ww/en/view/1142696)
7)
Manual "SIMATIC Distributed I/O ET 200iSP"
(https://support.industry.siemens.com/cs/ww/en/view/98821323)
8)
Manual "S7-400 Programmable Controllers Hardware and Installation"
(https://support.industry.siemens.com/cs/ww/en/view/1117849)
Special considerations when switching to CP443-1 (6GK7 443-1EX20-0XE0, 6GK7 443-1EX30-
0XE0)
● Discontinuation of CP 443-1 (6GK7443-1EX11-0XE0) as of 1 October 2009.
(https://support.industry.siemens.com/cs/ww/en/view/37325344)
● FAQ "What should you watch out for when upgrading from previous modules to the
successor module CP443-1 or CP443-1 Advanced?"
(https://support.industry.siemens.com/cs/ww/en/view/34894744)
