Siemens SIMATIC Rack PC 547B - Retrofitting Instructions

Appendix
A.4 Retrofitting instructions
SIMATIC Rack PC 547B
Operating Instructions, 12/2007, A5E01127519-02
113
A.4 Retrofitting instructions
The section below describes the approved variants of the drive configuration for
Rack PC 547B and the resultant operating conditions.
Approved configuration versions for the temperature range 5 to 35° C
'9'520RU
'9'EXUQHURU
+'LQUHPRYDEOHFDUWULGJH
'9'520RU
'9'EXUQHURU
+'LQUHPRYDEOHFDUWULGJH
'9'520RU '9'EXUQHURU +'LQUHPRYDEOHFDUWULGJH
)ORSS\
Figure A-1 For the temperature range 5 to 35° C
A removable cartridge with hard disk can be installed instead of DVD drive(s).
Devices equipped with removable cartridges may not to be exposed to shock during
operation as described by DIN IEC 600682.
Approved configuration versions for the temperature range 5 to 40° C
)ORSS\
'9'520
'9'520RU
+'LQWKHUHPRYDEOHFDUWULGJH
'9'520RU
+'LQWKHUHPRYDEOHFDUWULGJH
Figure A-2 For the temperature range 5 to 40° C
A removable cartridge with hard disk can be installed instead of DVD drive(s).
Devices equipped with removable cartridges may not to be exposed to shock during
operation as described by DIN IEC 600682.
