Specifications
13.4 Technical data of the telescopic rails
SIMATIC Rack PC 547B
98 Operating Instructions, 12/2007, A5E01127519-02
13.4 Technical data of the telescopic rails
Ultimate load per pair At least 30 kg
Full extraction length At least 470 mm
Rail thickness Maximum 9.7 mm
Mounting screws M5 x 6 mm
The mounting screws of the telescopic rails may not protrude by more than 5 mm into the
enclosure.
