Siemens SIMATIC Rack PC 547B - 13 Specifications; General Specifications

SIMATIC Rack PC 547B
Operating Instructions, 12/2007, A5E01127519-02
93
Specifications
13
13.1 General specifications
General specifications
Order numbers 6AG4104-0...(for details, refer to the ordering
documentation)
Dimensions 433.5 x 176.5 x 445.5 (WxHxD in mm) Detailed
dimension specifications are found in the "Dimension
drawings" section.
Weight Min. 16 kg, max. 23 kg
Supply voltage (V
N
) 100 V to 240 V AC (90 to 264 V AC)
Input current AC Continuous current up to 7 A (during startup up to 30 A
for the duration of 5 ms)
Frequency 50 – 60 Hz (min. 47 Hz to max. 63 Hz, sinusoidal)
Transient voltage interruption 16 ms at 0.85 U
N
(max. 10 events per; min. recovery time 1s)
Power consumption (with 210 W
secondary)
310 W (approx 68% efficiency)
Max. current output (AC) +3.3 V/24 A
+5V/26A
max. 190 W total allowed
-12V/15
+12V/15
-12V/0.2A
+5Vaux/2A
Noise emission < 45 dB (A) to DIN 45635
Degree of protection IP 30 with closed front door, IP 20 at the back in
conformity to EN 60529
Dust protection With the front panel closed according to IEC 60529
Filter class G2 EN 779, 99 % of particles > 0.5 mm are
filtered
Pollution gas EN 60721-3-3;1995 class 3C2
Sulphur dioxide and hydrogen sulphide class 3C3
Security
Protection class Protection class I compliant with IEC 61140
Safety regulations EN60950-1, UL60950, CSA C22.2 No 60950-00
