Specifications
13.1 General specifications
SIMATIC Rack PC 547B
94 Operating Instructions, 12/2007, A5E01127519-02
General specifications
Electromagnetic compatibility (EMC)
Emitted interference (AC) EN 55022 Class A, FCC class A
EN 61000-3-2 Class D, EN 61000-3-3
Noise immunity:
Mains borne disturbance variables on
supply lines
± 2 kV; (conforms to IEC 61000-4-4; Burst)
± 1 kV; (conforms to IEC 61000-4-5; Surge sym)
± 2 kV; (conforms to IEC 61000-4-5; Surge asym)
Noise immunity on signal lines ± 2 kV; (conforms to IEC 61000-4-4; Burst; length < 3 m)
± 2 kV; (conforms to IEC 61000-4-5; Surge sym, length >
30 m)
Immunity to discharges of static electricity ± 4 kV, contact discharge (to IEC 61000-4-2)
± 8 kV, atmospheric discharge (to IEC 61000-4-2)
Immunity to RF interference 1 V/m, 2-2.7 GHz
10 V/m, 80-1000 MHz und 1.4 - 2 GHz, 80% AM;
(conforms to IEC 61000-4-3)
10 V, 10 kHz-80 MHz; (conforms to IEC 61000-4-6)
Magnetic field 100 A/m, 50 Hz / 60 Hz; (to IEC 61000-4-8)
Climatic conditions
Temperature Tested to IEC 60068-2-2, IEC 60068-2-1,
IEC 60068-2-14,
- In operation
- Gradient
- Storage/transport
- Gradient
+ 5° to + 40° C without burner operation,
+ 5° to + 35° C with restriction
CPU up to 65W power loss
See "Retrofitting instructions"
max. 10° C/h no condensation
– 20° to +60° C
max. 20°C/h no condensation
Relative humidity Tested to IEC 60068-2-78, IEC 60068-2-30
- In operation
- Gradient
- Storage/transport
- Gradient
5% to 80% at 25 °C (no condensation)
max. 10°C/h no condensation
5% to 95% at 25 °C (no condensation)
max. 20°C/h no condensation
Mech. Ambient conditions
Vibration
- Operation
1 ,
Storage/transport
Tested to IEC 60068-2-6, 10 cycles
20 - 58 Hz, Amplitude 0.015mm; 58 to 200 Hz: 2m/s
2
5 - 8.51 Hz, Amplitude 3.5 mm; 8.51 to 500 Hz: 9.8 m/s
2
Shock resistance
- Operation
1
- Storage/transport
tested to DIN IEC 60068-2-27
half sine: 9,8 m/s
2
, 20 ms, 100 shocks per axis
half-sine: 250 m/s
2
, 6 ms, 1000 shocks per axis
Special features
Quality assurance to ISO 9001
Motherboard
Processor Design: LGA 775
Intel® Core™ 2 Duo E6600
(2.4 GHZ, 1066 MHz FSB, 4 MB L2C, EM64T, VT)
Intel® Core™ 2 Duo E4300
(1.8 GHZ, 800 MHz FSB, 2 MB L2C, EM64T)
Intel® Celeron® 440
(2.0 GHz, 800 MHz FSB, 512 KB L2C)
