Specifications
13.1 General specifications
SIMATIC Rack PC 547B
Operating Instructions, 12/2007, A5E01127519-02
95
General specifications
Chipset Intel 945G
RAID (on-board) Intel ICH7R with Intel storage manager software
Main memory 4 DIMM slots maximum 4 GB DDR 2 667 SDRAM
(PC 2 5300)
Memory expansion 512 MB to 4 GB, max. 3.2 GB can be used for operating
system and applications.
(See ordering documentation for features)
Expansion slots 4 x PCI
2 x PCIe x1
1 x PCIe x16
All modules up to 312 mm in length are supported
max. permissible power consumption
PCIe x1 slot
max. permissible power consumption
PCIe x16 slot
Max. permissible power consumption per
PCI slot
Max. accumulated power loss per PCI
slot
PCI modules with exclusively 5V supply
Max. permissible power loss at all slots
PCIe x1 modules: 3.3V 3A, 12V 2.1A; 3.3Vaux 0.4A
PCIe x16 module: 3.3V 3A; 12V 2.1A;
3.3Vaux 0.4A
5V 5A or 3.3V 7A, 12V 0.5 A, -12V 0.05 A;
3.3 Vaux 0.4A
Accumulated power loss (all voltages) may not exceed
25 W.
The total consumption of all modules may not exceed
25W
Total power consumption of 80 W must not be exceeded
In total, the 3.3 Vaux current of 1.2 A must not be
exceeded
Drives (for configuration details, refer to the order documentation)
Floppy disk drive 3.5" (1.44 MB)
HDD 3.5" SATA 300, 250 GB
DVD-ROM 5.25" ATAPI
Read:
DVD ROM: Single layer 16x, Dual Layer 8x
DVD+R/RW, DVD-R/RW 8x, DVD-RAM 2x
CD-ROM, CD-R 32x, CD-RW 20x
DVD burner 5.25" ATAPI
Read:
DVD-ROM: Single Layer 16x, Dual Layer 12x
DVD-R/+R: Single Layer 16x, Dual Layer 7x
DVD-RW/+RW 13x
CD-ROM/CD-R 48x, CD-RW 40x
Writing:
DVD+R 18x, DVD+RW 8x, DVD-R 18x, DVD-RW 6x,
DVD+R9 (DL) 8x, DVD-R DL 8x
CD-R 48x, CD-RW 32x
Graphics
Graphics controller Intel® GMA950 graphics controller,
chipset integrated 2-D and 3-D engine,
Up to 2048 x 1536 at 75 Hz
Graphics memory Dynamic Video Memory Technology
(uses up to 224 MB of RAM)
