Readers
5.4 SIMATIC RF680R
SIMATIC RF600
156 System Manual, 11/2018, J31069-D0171-U001-A21-7618
5.4.3 Installation/mounting
Requirement
Note that the readers only have the specified degree of protection when all connectors are
in use or when unused connectors are closed with the protective caps.
Close any connectors on the reader that you are not using with protective caps. You can
order the protective cap set using the article number specified in the section "Ordering
data".
The transmitter complies with the requirements of Health Canada and the FCC limit values
for subjecting persons to HF radiation, provided that a minimum spacing of 26 cm exists
between antenna and person. When the antennas are installed, you must therefore ensure
that a minimum spacing of 26 cm is maintained between personnel and antennas.
5.4.3.1 Mounting/Installation
Mounting/installing the device
You can mount the reader in the following ways:
● DIN rail T35 (S7-1200)
● S7-300 standard rail
● S7-1500 standard rail
● directly on a flat surface using the VESA 100 mounting system (torque ≃ 1.5 Nm).
The positions of the mounting holes for the device are shown in the section Dimension
drawing (Page 164).
