Siemens SIMATIC RF600 Series User Manual

Antennas
6.2 SIMATIC RF615A
SIMATIC RF600
208 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.2.2 Ordering data
Table 6- 4 RF615A ordering data
Product
Article number
SIMATIC RF615A (ETSI)
6GT2812-0EA00
SIMATIC RF615A (FCC) 6GT2812-0EA01
Table 6- 5 Ordering data accessories
Product
Article number
Connecting cable between
reader and antenna
1 m (cable loss 0.5 dB)
6GT2815-0BH10
3 m (cable loss 1.0 dB) 6GT2815-0BH30
5 m, suitable for drag chains
(cable loss 1.5 dB)
6GT2815-2BH50
10 m (cable loss 2.0 dB)
6GT2815-1BN10
10 m (cable loss 4.0 dB)
6GT2815-0BN10
15 m, suitable for drag chains
(cable loss 4.0 dB)
6GT2815-2BN15
20 m (cable loss 4.0 dB)
6GT2815-0BN20
40 m (cable loss 5.0 dB)
6GT2815-0BN40
6.2.3 Mounting
Two holes for M4 screws are provided for mounting the antenna. The antenna is suitable for
mounting on metallic and non-metallic surfaces.
Note
Maximum read/write range
The maximum read/write ranges are only reached when the
antenna is mounted on a
metallic surface with a minimum size of 150 x 150
mm.
Note
Antenna gain depends on the mounting surface
Note that the antenna gain depends on the material of the mounting surface. If the antenna
is mounted on a metallic surface,
the antenna gain is -5 dBi. If the antenna is mounted on a
non
-metallic surface, the antenna gain is -13 dBi.
