Transponder
7.14 SIMATIC RF680T
SIMATIC RF600
438 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.14.5 Dimension drawing
Figure 7-41 Dimension drawing of SIMATIC RF680T
All dimensions in mm
Tolerances unless indicated otherwise ±0.5 mm.
7.14.6 Certificates and approvals
Table 7- 57 6GT2810-2HG80 - RF680T
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Conformity with the ATEX directive 2014/34/EU
Table 7- 58 6GT2810-2HG80 - RF680T
Federal Communications
Passive labels or transponders comply with the valid regulations;
certification is not required.
This product is UL-certified for the USA and Canada.
It meets the following safety standard(s):
• UL508 - Industrial Control Equipment
• CSA C22.2 No. 142 - Process Control Equipment
• UL Report E 120869
