Transponder
7.11 SIMATIC RF630T
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
399
7.11 SIMATIC RF630T
7.11.1 Characteristics
The SIMATIC RF630T transponder is a passive (i.e. battery-free) and maintenance-free,
cylindrical data carrier. It operates based on UHF Class 1 Gen 2 technology and is used to
save the "Electronic Product Code" (EPC) of 96 bits/240 bits. The transponder also has a
512-bit user memory.
Areas of application include the mounting of metallic components (e.g. engine assembly in
the automobile industry) as well as RF identification of tools, containers and metal frames.
The RF630T is small and rugged and suitable for industrial applications with IP68/IPX9K
degree of protection. It is highly resistant to oil, grease and cleaning agents.
The SIMATIC RF630T is mounted directly onto metal surfaces to ensure optimum
functioning.
Area of application
Identification tasks in rugged industrial environ-
Frequency range
• ETSI: 865 to 868 MHz
• FCC: 902 to 928 MHz
According to ISO 18000-63
Memory
• EPC: 96 ... 240 bits
• User memory: 64 bytes
1)
Mounting Designed for direct mounting on conductive mate-
rials (preferably metal).
1)
Depending on the environment, the reader/the antennas and the set power
