Antennas
6.3 SIMATIC RF620A
SIMATIC RF600
240 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.3.7 Technical data
Table 6- 13 Technical specifications for the RF620A antenna
• ETSI • 865 to 868 MHz
• FCC • 902 to 928 MHz
• ETSI • ≤ 340 mW ERP
• FCC • ≤ 560 mW EIRP
• CMIIT • ≤ 2000 mW ERP
• ARIB • STD-T107: RF650R: ≤ 500 mW EIRP
• STD-T106: RF680R/RF685R: < 4000 mW
EIRP
• ETSI • Depends on background,
refer to the section "Antenna pattern ETSI
(Page 233)"
• FCC • Depends on background,
refer to the section "Antenna pattern FCC
(Page 236)"
Opening angle for sending/receiving when mounted on a metal surface of 15 cm x 15 cm
1)
• ETSI • Horizontal plane: 100°
Vertical plane: 75°
see section "Antenna pattern ETSI
(Page 233)"
• FCC • Horizontal plane: 130
Vertical plane: 105°
see section "Antenna pattern FCC
(Page 236)"
