Siemens SIMATIC RF600 Series - Dimension Drawing; Certificates and Approvals

Transponder
7.3 SIMATIC RF640L Smartlabel
SIMATIC RF600
System Manual, 11/2018, J31069-D0171-U001-A21-7618
359
7.3.5 Dimension drawing
①
Printable area
②
Polarization axis
③
Conveyor direction
Figure 7-10 RF640L dimension drawing
All dimensions in mm
7.3.6 Certificates and approvals
Certificate
Description
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Federal Communications
Commission
Passive labels and transponders comply with the valid regulations;
certification is not required.
