Siemens SIMATIC RF600 Series - Technical Data

Transponder
7.2 SIMATIC RF630L Smartlabel
SIMATIC RF600
350 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.2.3 Technical data
Table 7- 9 Technical specifications of the transponder SIMATIC RF630L
6GT2810-2AB00
Product type designation
SIMATIC RF630L
Radio frequencies
Operating frequency
860 to 960 MHz
Memory
Chip (manufacturer/type)
IMPINJ / MONZA 2
Memory type
EEPROM
Memory configuration
• EPC • 12 bytes / 96 bits
• User memory • 12 bytes / 96 bits
• TID • 4 bytes / 32 bits
Number of write cycles (< 40 °C)
> 10
5
Number of read cycles (< 40 °C)
> 10
14
Data retention time (< 40 °C)
10 years
Electrical data
Range
≤ 8 m
1)
Protocol
ISO 18000-63
Transmission speed
≤ 320 kbps
Polarization
Linear
Mechanical specifications
Material
Paper
Silicone-free
Yes
Color White
Antenna material Aluminum
Type of antenna
Shortened dipole
Printing
Can be printed using heat transfer technique
Roll core diameter
76 mm
Roll outer diameter
≤ 120 mm
