Siemens SIMATIC RF600 Series - Antenna Mounting Kit

Accessories
10.3 Reader and antenna holders
SIMATIC RF600
480 System Manual, 11/2018, J31069-D0171-U001-A21-7618
10.3.3 Antenna mounting kit
Flexible mounting is possible using the antenna mounting kit. An antenna can then be
rotated in any direction in space.
Antenna mounting kit
Description
Pivot range of antenna mounting kit
① Wall side
② Antenna side
Dimensions/clearances of antenna mounting kit
