Antennas
6.2 SIMATIC RF615A
SIMATIC RF600
222 System Manual, 11/2018, J31069-D0171-U001-A21-7618
6.2.7 Technical data
Table 6- 7 Technical specifications for the RF615A antenna
6GT2812-0EA0x
Product type designation
SIMATIC RF615A
Radio frequencies
Operating frequency
• ETSI • 865 to 868 MHz
• FCC • 902 to 928 MHz
Maximum radiated power
• ETSI • ≤ 340 mW ERP
• FCC • ≤ 560 mW EIRP
• CMIIT • ≤ 340 mW ERP
• ARIB • STD-T107: RF650R: ≤ 500 mW EIRP
• STD-T106: RF680R/RF685R: < 560 mW
EIRP
Antenna gain
-13 dBi ... -5 dBi
• ETSI • Depends on background,
refer to the section "Antenna pattern ETSI
(Page 215)"
• FCC • Depends on background,
refer to the section "Antenna pattern FCC
(Page 218)"
Opening angle for sending/receiving
when mounted on a metal surface of 15 cm x 15 cm
1)
• ETSI • Horizontal plane: 100°
Vertical plane: 75°
see section "Antenna pattern ETSI
(Page 215)"
• FCC • Horizontal plane: 130
Vertical plane: 105°
see section "Antenna pattern FCC
(Page 218)"
Electrical data
Range See section "Maximum read/write ranges of
transponders (Page 341)"
Impedance
50 Ω
Polarization
Linear
VSWR (standing wave ratio)
≤ 2:1
