Siemens Simatic S7-1500 CPU 1512C-1 PN

Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
159
Article number
6ES7512-1CK01-0AB0
• PID_3Step
Yes; PID controller with integrated optimization
for valves
• PID-Temp
Yes; PID controller with integrated optimization
for temperature
Counting and measuring
• High-speed counter
Yes
Integrated Functions
Number of counters
6
Counting frequency (counter) max.
400 kHz; with quadruple evaluation
Counting functions
• Continuous counting
Yes
• Counter response parameterizable
Yes
• Hardware gate via digital input
Yes
• Software gate
Yes
• Event-controlled stop
Yes
• Synchronization via digital input
Yes
• Counting range, parameterizable
Yes
Comparator
– Number of comparators
2; per count channel; see manual for details
– Direction dependency
Yes
– Can be changed from user program
Yes
Position detection
• Incremental acquisition
Yes
• Suitable for S7-1500 Motion Control
Yes
Measuring functions
• Measuring time, parameterizable
Yes
• Dynamic measurement period adjustment
Yes
• Number of thresholds, parameterizable
2
Measuring range
– Frequency measurement, min.
0.04 Hz
– Frequency measurement, max.
400 kHz; with quadruple evaluation
– Cycle duration measurement, min.
2.5 µs
– Cycle duration measurement, max.
25 s
