Siemens Simatic series User Manual

Device maintenance and repair
7.3 Manage onboard RAID system
SIMATIC IPC547G
108 Operating Instructions, 04/2020, A5E49948632-AA
7.3.3 RAID software
The RAID software "Intel Rapid Storage Technology" offers advanced functions to use and
manage the RAID system.
1. Select the RAID software via "Start > Programs > Intel Rapid Storage Technology".
2. Select "Manage" > "Advanced" to display details of the RAID system.
3. Select "Help" > "System Report" > "Save" to create a report with the details of the RAID
system.
7.3.4 Checking the status of the RAID system
By default, the status of the RAID system is displayed in the Windows Event Viewer and in a
log file of the program. If an error occurs, a hard disk can be synchronized at the operating
system level.
Note
It may take a very long time (hours or even days in the case of a high drive load) to
synchronize a new hard disk in the background, depending on its size and on the system
load.
The redundant system state is reached again only after synchronization is co
mpleted.

Siemens Simatic series Specifications

General

Processor	Intel Core i3, Core i5, Core i7
Operating System	Windows 10 IoT Enterprise, Linux
Storage	SSD, HDD
Interfaces	Ethernet, USB, RS-232/485
Ports	Ethernet, USB, Serial
Mounting	DIN rail, wall
Protection Class	IP65
Graphics	Integrated Intel HD Graphics
Expansion Slots	PCIe
Power Supply	24V DC or 100-240V AC
Operating Temperature	0°C to 50°C (depending on model)
