SIMATIC IPC547G
Operating Instructions, 04/2020, A5E49948632-AA
65
Expanded device functions
5.1 Monitoring functions
5.1.1 Overview of the monitoring functions
SIMATIC IPC DiagBase software
Even in its basic version, the device supports the use of monitoring functions. The SIMATIC
IPC DiagBase software, which is included in the scope of delivery, provides the following
local display, monitoring and control functions:
● Temperature monitoring (over-temperature, under-temperature or cable break at a
temperature sensor)
● Fan monitoring (fan speed too low, fan failure, or a break in a tachometer line)
● Monitoring of drives (HDD and SSD) with S.M.A.R.T functionality even in a RAID system
● Watchdog (hardware or software reset of the computer)
● Operating hours meter (information on the cumulative run time)
● Battery monitoring. The charge level of the CMOS battery is monitored.
Use the "Management Explorer" application for clear control. Use the "Alarm Manager" to
receive notifications about individual alarms.
Note
Additional information on the functionality of the SIMATIC IPC DiagBase software is
available in the online help.
SIMATIC IPC DiagMonitor software
The SIMATIC IPC DiagMonitor software is available on DVD and can be ordered as an
option with the configurator. The software is included with the device when you order it. The
SIMATIC IPC DiagMonitor software offers additional alarm and linking options in addition to
the local monitoring functions of the SIMATIC IPC DiagBase software and includes:
● The software for the stations to be monitored.
● A library for creating user-specific applications.
IPC DiagMonitor only supports the device hardware as of version 4.5.2.
Older versions do not support the device hardware.
